Wesjon aluminum cablebridge
SPECS CABLE BRIDGE
- Durable aluminum Architectal 6060.22 manufactured from 80% recycled aluminum, equipped with X-ECO label
-
Lid with long spring clip, which ensures a perfect click and always can be opened with a coin, key, or large paperclip
- The cable bridge is filled from above.
- Two major cable channels 25 and 35 mm, maximum diameter 14.5 mm, see cross section below
- Link capability with a metal strip, which is mounted in an integrated recess
-
Additional metal strips are to be ordered separately
-
Patented freewheel chamber allowing the lid with a "user pollution" continues to function
-
Cablechannels with centregroove for easy screwing
-
Optional provided with 3 anti-slip strips manufactured by coextrusion HPVC / TPE for a perfect grip on any surface and is ideal where screwing is not allowed.
- 6 rows of teeth on the bottomside for a perfect grip on carpet floors
- Light industrial weight about 500 kg (elevator, coffee cart, station wagon, wheelchairs)
- Maximum size custom color anodizing or length size from 1,500 kg.
- Saw service directly at the profile
- Customized service, super high finish by Bomar 500 sawmill which by its hydraulic drive provides an impetus and burr-free cut free and also perfect bevel cuts
- When cutting the profiles the length is always rounded up to the next available size. For example: You order a profile of 93 cm, you need to order over 120 cm.
- Individual components available for interior and exterior angle and 90 ° flat angle
- Weight m‘ = ± 2 kg
- Download English product brochure
